Conveyor Belt Vulcanizing Equipments

Conveyor Belt Vulcanizing Press

Product description: CVUL Conveyor Belt Vulcanizing press is an ideal vulcanizing equipment for on-site hot splicing of fabric, nylon steelcord belt, as well as hot jointing of anti-corrosion, heat resistant and other spe
INQUIRY

CVUL Conveyor Belt Vulcanizing press is an ideal vulcanizing equipment for on-site hot splicing of fabric, nylon steelcord belt, as well as hot jointing of anti-corrosion, heat resistant and other special conveyor belt.

CVUL Conveyor Belt Vulcanizer has the specialities of small volume, light weight, three-phase power supply, uniform heating and uniform pressure of water supply.
Equipped with light automatic electronic control box, the connection between the electric control box and the host is completed by the integrated plug-in and multi-core cable, which is easy to operate and reliable.

The quality of splice will directly influence the working efficiency and life span of the conveyor belt, especially for the long distance and high-strength conveyer belt system. Therefore, CVUL conveyor belt vulcanizing press will be your necessary equipment that keeps your conveyor belt running in good condition and reduces downtime.

CVUL will recommend the best solution for your case, if provides valuable info belows:

● Max belt width.
● Heating plate size & angle.
● Belt type and strength.
● Working voltage & pressure requirments.

Conveyor Belt Vulcanizing press - CVUL
Model	Width of Vulcanized Belt (mm)	Specification	Size of heating plate (L×W) mm	Power (Kw)	Dimension L× W × H (mm)	Weight (Kg)
Model	Width of Vulcanized Belt (mm)	Specification	Size of heating plate (L×W) mm	Power (Kw)	Dimension L× W × H (mm)	Weight (Kg)
CBVP-650	650	650×830	*830×82031**	10.8	1140×830×585	440
CBVP-650	650	650×1000	*1000×82031**	13	1140×1000×585	530
CBVP-800	800	800×830	*830×99531**	12.7	1320×830×585	515
CBVP-800	800	800×1000	*1000×99531**	15.4	1320×1000×585	630
CBVP-1000	1000	1000×830	*830×122831**	15	1450×830×585	600
CBVP-1000	1000	1000×1000	*1000×122831**	18	1450×1000×585	715
CBVP-1200	1200	1200×830	*830×143131**	18.2	1700×830×750	890
CBVP-1200	1200	1200×1000	*1000×143131**	22	1700×1000×750	1030
CBVP-1400	1400	1400×830	*830×165331**	20.6	1950×830×750	980
CBVP-1400	1400	1400×1000	*1000×165331**	24.6	1950×1000×750	1180
CBVP-1600	1600	1600×830	*830×186731**	22.8	2150×830×795	1290
CBVP-1600	1600	1600×1000	*1000×186731**	27.2	2150×1000×795	1540
CBVP-1800	1800	1800×830	*830×207931**	25	2380×830×900	1370
CBVP-1800	1800	1800×1000	*1000×207931**	30	2380×1000×900	1600
CBVP-2000	2000	2000×830	*830×230331**	27.4	2620×830×980	1500
CBVP-2000	2000	2000×1000	*1000×230331**	33	2620×1000×980	1780
CBVP-2200	2200	2200×830	*830×247831**	29.8	2830×830×980	1680
CBVP-2200	2200	2200×1000	*1000×247831**	35.8	2830×1000×980	1990
